Prouduct

80w 100w 150w

 InputInput VoltageAC198-AC250V or AC99V-AC125V(Pls speciy when placing order)AC frequency47—440HZMax Input Power550WMax Input Current5AOutputMax Output VoltageDC 40KVMax Output CurrentDC 25mAEff

  • Model:



Input

Input Voltage

AC198-AC250V or AC99V-AC125VPls speciy when placing order

AC frequency

47—440HZ

Max Input Power

550W


Max Input Current

5A


Output

Max Output Voltage

DC 40KV

Max Output Current

DC 25mA

Efficiency

≥90﹪(full load

Mean Time Between Failure (MTBF)

≥10000H

Response Speed

≤1msfrom the switch Signal is given to the output current up to 90% of the setting current

Control Interface

TTL level switch control; high or low effective level can be chosen (details refer to the control terminal specification)

Pressure-proof

Input-Output, Input-Shell: AC1500V 10MA 60S; Output negative is connected with machine shell.

Protection

can work in open-circuit condition for a short timeRequire a good protective earthing and avoid arc between the positive and the machine shell

Environmental

Operating Temperature-10~40℃Relative Humidity (RH)≤90

Cooling Way

Force-Air Cooling (FAC)

Dimension

L×W×H=280*173*97(mm)




Input

Input Voltage

AC198-AC250V or AC99V-AC125VPls speciy when placing order

AC frequency

47—440HZ

Max Input Power

1000W


Max Input Current

10A


Output

Max Output Voltage

DC 50KV

Max Output Current

DC 38mA

Efficiency

≥90﹪(full load

Mean Time Between Failure (MTBF)

≥10000H

Response Speed

≤1msfrom the switch Signal is given to the output current up to 90% of the setting current

Control Interface

TTL level switch control; high or low effective level can be chosen (details refer to the control terminal specification)

Pressure-proof

Input-Output, Input-Shell: AC1500V 10MA 60S; Output negative is connected with machine shell.

Protection

can work in open-circuit condition for a short timeRequire a good protective earthing and avoid arc between the positive and the machine shell

Environmental

Operating Temperature-10~40℃Relative Humidity (RH)≤90

Cooling Way

Force-Air Cooling (FAC)

Dimension

L×W×H=325*240*97(mm)
